SquareTrade © AP6.0Visit our storeSupermicro PDSMU 1U SuperServer SATA LGA775 MotherboardBest Single CPU Dual-core Server Motherboard Motherboard Specs: Sockets: LGA 775 Supported CPU's: Intel Xeon 3200 / 3000 Series, Core 2 Quad / Duo / Extreme Series, Pentium D, Pentium Extreme Edition, Pentium 4 & Celeron D in LGA775 Package NOTE: This board DOES NOT support Q9000, E8000, E7000, E5000 series or other 45nm processors (FSB Support: 1066/800/533MHz) Chipset: Intel 3010 Graphics: On-board ATI ES1000 (16MB) graphics Memory: Four 240-pin DIMM sockets Supports up to 8 GB of memory (Single / Dual Channel) DDR2 667/533MHz unbuffered, ECC / non-ECC SDRAM, 240-pin gold-plated DIMMs Storage Controller: Intel ICH7R SATA2 (3 Gbps) controller built-in RAID Support: Intel: RAID 0, 1, 5, 10 support (Windows Only) Adaptec: RAID 0 (Two, three, four drives only) RAID 1 (Two hard drives only) Outputs: Four Serial ATA ports (3 Gbps performance) Four SATA hard drives supported One EIDE channel supports up to two UDMA IDE devices Supports UDMA Mode 5, PIO Mode 4, and ATA/100 1 Floppy controller; 1.44 MB 2x RJ45 LAN ports Up to 6x USB 2.0 / 1.1 compliant ports 2 rear ports 2 internal header for 4 USB 2.0/1.1 ports 1x VGA port PS/2 keyboard and mouse ports 1x Fast UART 16550 serial port 1x internal header Slots: 1 Universal (UIO) slot Used in conjunction with Supermicro UIO Controller Card 2 (x8) PCI-e slot 1 (x4) PCI-e slot Included in the Box: Motherboard Only Condition: Refurbished Warranty: 30 Days compeve Store
